Prefabricated and Compact Substation Packages

Project-based prefabricated substations combining MV/RMU, transformer, LV panels and enclosure. Define capacity, voltage ratio, layout and supply boundaries with JCON ELEC.

Request a QuoteReference ratingsConfiguration routes
Mianyang workshop with power distribution cabinets under assembly
Manufacturing reference showing distribution cabinet assembly, not the exterior of a complete prefabricated substation. Confirm the offered enclosure and internal arrangement from project drawings and matching photographs.

Scope of supply

A compact substation quotation is a coordinated equipment package, not just an enclosure or a list of cabinets. JCON ELEC reviews the MV unit, transformer, LV distribution and auxiliary systems against the single-line diagram and site arrangement.

Price and lead time follow the confirmed drawings, component brands and supply scope. The quotation must state packing, freight, destination, Incoterms and any site-service exclusions.

Manufacturing capabilityQuality documents

Reference ratings

Voltage referenceJCON reference data lists a 24 kV MV side and a 0.4 kV LV side. Other project voltages require a separate technical review.
Current reference630 A on the MV side; 1250 A on the LV side. Transformer capacity and each circuit rating are confirmed independently.
Fault-duty reference20 kA for 4 s is listed in the source materials; confirm the applicable circuit and matching verification documents before selection.
Enclosure and standards referenceIP33; GB/T 17467-2020 and DL/T 537-2018 as listed in JCON materials. Final design and applicable editions require project confirmation.

Reference: JCON product materials. These values are not a guaranteed combined configuration; approved drawings and applicable verification documents govern the offer.

Configuration routes

These are RFQ routes, not pre-engineered packages. Confirm the actual ratings, brands and verification basis before ordering.

ApplicationConfiguration to reviewBuyer inputs
Coordinated MV-transformer-LV packageRequest this configurationReview RMU/MV equipment, transformer, LV panels, enclosure and auxiliary systems as separately identified items.SLDs, transformer capacity/ratio, feeder list, site layout and the required inclusion/exclusion list.
Cabinets or enclosure with buyer-supplied transformerRequest this configurationThe buyer-supplied equipment and the supplier's interfaces must be explicit; this is not the same price scope as a complete package.Transformer dimensions, losses, terminal arrangement, delivery responsibility and interface information.
Solar, storage or industrial project packageRequest this configurationReview project-specific receiving/step-up duty and auxiliary distribution without assuming one standard layout.Equipment voltage levels, protection/metering requirements, site climate, transport limits and commissioning boundary.

Documents and acceptance scope

Agree document deliverables and checks against the offered assembly. A company certificate or standards reference does not verify every configuration.

For quotationMV/LV SLDs, transformer schedule, enclosure/site dimensions, required accessories and delivery terms.
For design approvalEquipment arrangement, transformer interfaces, ventilation, earthing, access clearances and any transport split.
For acceptanceAgreed inspection and interface checks for the supplied equipment, final drawings, packing list, dimensions and weights. Site installation and commissioning remain defined project responsibilities.
Quality documentsProject references
FAQ

Buyer questions

Is the transformer always included in the price?No. The quotation must identify the transformer, MV/RMU, LV panels, enclosure and auxiliaries separately, stating what is included, excluded or supplied by the buyer.
Is this a 10 kV or a 24 kV substation?The published JCON reference data is for a 24/0.4 kV configuration. A 10 kV or another voltage project needs its own SLD and equipment review; ratings are not transferred automatically between versions.
Does 1250 A specify the transformer capacity?No. It is an LV current reference, not a transformer kVA rating. Provide the required transformer capacity, voltage ratio and load schedule for a coordinated design.
Can the package be energized immediately after delivery?Factory integration does not replace site installation checks, earthing, protection settings, commissioning or local acceptance. Agree the responsibilities and acceptance procedure before ordering.
