Schneider MVnex
Authorized medium-voltage cabinet platform material for project review.
Documents for customer review
Authorization, ISO systems, CQC certificates and type test reports.
JCON's qualification package contains authorization materials, ISO system certificates, CQC certificates and product test reports covering major medium-voltage and low-voltage equipment series.
Certificate scope
The customer review materials include Schneider Electric and Siemens authorized cabinet system documents, ISO 9001/14001/45001 system certificates, CQC certificates, type test reports, patent and enterprise honor materials. For external use, each document should be matched to the exact product model and project scope.
- Authorization documents for selected Schneider Electric and Siemens cabinet platforms.
- ISO quality, environmental and occupational health and safety management systems.
- CQC certificates and type test reports for major cabinet series.
- Patent, enterprise honor and site management materials for supplier review.
Supplier review package
Documents customers usually request before technical approval.
Switchgear qualification is not only about having certificates. For project review, each document should be matched to the cabinet type, rated parameters, selected components and destination market.
Management systemsISO 9001, ISO 14001 and ISO 45001 certificates for supplier registration and preliminary audit.
Product certificatesCQC certificates, type test reports and other product evidence matched to the selected switchgear series.
Authorized platformsSchneider Electric MVnex, Schneider Prisma E, Siemens SIVACON 8PT and Siemens SIBOARD related cabinet platform documents.
Factory capabilityWorkshop, assembly, busbar processing, secondary wiring, routine inspection and site management materials.
Factory testsRoutine inspection records covering visual checks, mechanical operation, interlock, secondary circuits, insulation and withstand tests.
Delivery documentsDatasheets, drawings, deviation list, manuals, nameplate information, packing list and project photos when required.
Authorized systems
Cabinet platform documents available for qualified projects
Brand-related wording should always match the actual authorization document, cabinet type and project scope.
Schneider Prisma E
Low-voltage distribution cabinet system qualification material.
Siemens SIVACON 8PT
Authorized low-voltage cabinet platform material for higher-standard projects.
Siemens SIBOARD
Document support for SIBOARD low-voltage distribution cabinet projects.
ISO and product certificates
View-only previews for online qualification review
The public website shows certificate previews only. Formal copies should be issued during project clarification according to the requested model, standard and destination market.
ISO 9001
Quality management system certificate.
ISO 14001
Environmental management system certificate.
ISO 45001
Occupational health and safety management system certificate.
CQC Certificate
Product certification materials for selected switchgear series.
Type Test Report
Test-report preview for technical and supplier review.
Enterprise Honors
Honor and qualification displays from the Mianyang company materials.
Quality Culture
Internal management and quality culture materials for audit context.
Safety Management
Workshop management board from the production environment.
Company profile files may be downloaded for supplier screening. Qualification and certificate materials are displayed as previews on this website; project-specific copies should be requested through the RFQ email.
Quality control workflow
Closed-loop control from technical clarification to delivery documents.
Many switchgear quality issues start from unclear parameters, inconsistent component selection or missing documents. JCON manages technical review, production control, testing and document preparation in one project workflow.
1. Technical review
Check single-line diagram, BOQ, voltage, current, short-circuit rating, IP level and project standards.
2. Design confirmation
Confirm cabinet type, main circuit, protection, component brand, authorized platform and technical deviations.
3. Production control
Control sheet metal, busbar, assembly, secondary wiring and internal inspection according to drawings.
4. Factory inspection
Check mechanical operation, interlocks, insulation, withstand tests, secondary circuits and functional performance.
5. Document filing
Prepare certificates, reports, drawings, photos, manuals, packing lists and delivery records.
6. Project support
Provide additional files according to Incoterms, destination, customer audit format and project requirements.
Company profile
Download the company introduction for preliminary review.
The profile provides a broader view of company structure, product range, manufacturing process, project experience and service contact.
